WI-POE58-BT

● 1*100/1000Mbps PoE output port with 802.3bt 90W
● 1*100/1000Mbps Ethernet input port
● AC IN 100-240V
● Metal casing with high quality
● Support desktop and wall mount

HARDWARE FEATURES

WI-POE58-BT

Interface

1 10/1000Mbps PoE RJ45 Port

1 10/1000Mbps Ethernet Port

Network Media

10BASE-T: UTP category 3, 4, 5 cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

100BASE-TX: UTP category 5, 5e cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

Power Supply

AC IN 100-240V

Data In/Out

110/1000Mbps Data In

Power In/Out Port

1 x 802.3 af/at/bt 90W PoE Out

PoE PIN

1/2(-)3/6(+);4/5+  7/8-

PoE Consumption

52V 90W

LED Indicator

PWR-Power

DIP Switch

N/A

Fan Quantity

Fanless

Background Bandwidth

2Gbps

Transmission Method

Store-And-Forward

Protection Level

6kV Lightning protection

6kV ESD Contact discharge

Advanced Functions

Mac Address Auto-Learning And Auto-Aging

Store and forward

IEEE 802.3x  flow control for

Full-duplex Mode

Backpressure for Half-duplex Mode

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

205×134×47mm

DeviceDimension

113×48×30mm

Gross Weight

0.74kg

Net Weight

0.5kg

Package Contents

1 x PoE Switch

1 x Power Cord

1 x Quick Installation Guide

Operating Temperature

-10°C~55°C
