Model
|
WI-PMS310GF-Alien-I
|
Hardware Features
|
Downlink Ports
|
8*10/100/1000 Base-T PoE RJ-45(Auto-MDI/MDI-X)
|
Uplink Ports
|
2*1000 Base-X SFP
|
Console Port
|
1*RJ-45 to RS-232 console port (115200,8,N,1)
|
Alarm In/Out Interface
|
Yes
|
PoE
|
PoE Standard
|
Ports 1-2 : 802.3 af/at/bt 60W
Ports 3-8 : 24V Passive/48V 802.3af/at PoE
|
PoE Power Supply Type
|
Mid-span, End-span
|
PoE Budget
|
360W
|
Boost PoE Budget
|
120W
|
Switch Property
|
Standards
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1x
|
Forwarding Modes
|
Store and forward
|
Packet Buffer
|
4.1Mbit
|
MAC Table
|
8K
|
Switching Capacity
|
20Gbps / non-blocking
|
Packet Forwarding Rate
|
14.88Mpps
|
Switch Property
|
Input Voltage
|
Power 1 (Main): 37~57V DC
Power 2 (Backup): 37~57V DC
Boost Power 3: 9-52V
|
Reliability
|
Surge Immunity
|
6kV, Standard: IEC6000-4-5
|
ESD Protection
|
8kV Contact Discharge, 15kV Air Discharge, Standard: IEC61000-4-2
|
MTBF
|
about 30Wh
|
MTBF Standards
|
Telcordia SR-332,25℃
|
Operating Temperature
|
-40℃~80℃
|
Storage Temperature
|
-40℃~85℃
|
Operating Humidity
|
5%~95% (Non-condensation)
|
Physical Parameter
|
Led Indicators
|
2* power supply indicators
1* system working indicator
2* SFP indicator
8* RJ45 PoE indicators 8* RJ45 Link indicators
|
Dimensions (W*D*H)
|
167*130*73mm
|
Net Weight
|
1.7kg
|
Installation
|
Desktop/DIN-rail/wall mounting
|
Certifications
|
Certifications
|
CE, FCC
|
Software Features
|
Industrial Switch Monitoring
|
Temperature sensor, alarm input and output
|
Spanning Tree
|
IEEE 802.1D -STP
|
IEEE 802.1w -RSTP
|
IEEE 802.1s -MSTP
|
Reliability
|
Port Loop Detection
|
EAPS
|
ERPS
|
LLDP/LLDP-MED
|
UDLD
|
VLAN
|
Max 4K VLAN Groups
|
802.1q Tagged VLAN
|
MAC-Based VLAN
|
IP-Based VLAN
|
Protocol-Based VLAN
|
QinQ
|
802.1q-Based VLAN
|
Voice VLAN
|
Port
|
LACP
|
Jumbo Frame
|
Port Shutdown
|
Link Aggregation (Up to 8 aggregation groups and up to 8 ports per group)
|
Port Mirroring (One-to-One Many-to-One Tx/Rx/Both)
|
Security
|
IP-MAC-Port Binding
|
Support Static and Dynamic ARP
|
DHCP Snooping
|
IEEE802.1x AAA
|
RADIUS/TACACS+
|
RADIUS
|
Security
|
Port Isolation
|
Port Based Authentication
|
Secure Command Line Interface (CLI) Management With SSHv1/SSHv2
|
Broadcast/Multicast/Uni-cast Storm Control
|
Port MAC Address Filtering
|
Access Control List
|
Standard IP-Based ACL
|
Extended IP Based ACL
|
MAC IP-Based ACL
|
MAC ARP-Based ACL
|
IPv6-Based ACL
|
ACL Port Filtering
|
Time-Based ACL
|
QOS
|
Port-Based (uplink and downlink traffic of a single port can be restricted)
|
802.1p-Based Classification
|
Support WRR, SP, WFQ
|
DISC-Based Classification
|
CAL-Based Classification
|
L2 Multicast
|
IGMP Snooping V1/V2/V3
|
MLD Snooping
|
MVR
|
IPv6
|
IPv4/IPv6 Dual Protocol Stack
|
IPv6 Neighbor Discovery
|
Support manual address configuration, stateless address auto-configuration and tasteful address configuration obtained through DHCPv6 client
|
IPv6 TFTP
|
IPv6 SNMP
|
ICMPv6
|
IPv6 Path MTU Discovery
|
IPv6 SSH
|
Tracert6
|
Management
|
Web-Based GUI
|
Command Line Interface (CLI) through console port, telnet and SSH
|
SNMPv1/v2c/v3 Trap/Inform RMON (1, 2, 3, 9) groups
|
Password Recovery
|
SNTP
|
System Log
|
Traceroute
|
Ping
|
Management
|
CPU Monitoring
|
Firmware Upgrade
|
Configuration Export/Import
|
Support SNTP Based IPv4 and IPv6
|
DHCP/BOOTP Client
|
