WI-POE55S-BT-I-DC
● 1*100/1000Mbps PoE output with 802.3af/at/bt 90W
● 1*100/1000Mbps Ethernet output port
● DC Output 12V/16V/24V/48V
● Working temparature:-40℃~80℃
● Metal casing with high quality
● Support desktop and DIN-rail mount
HARDWARE FEATURES
WI-POE55S-BT-I-DC
Interface
1 10/1000Mbps PoE RJ45 Port
1 10/1000Mbps Ethernet Port
Network Media
10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
Power Supply
48-55V PoE IN
Data In/Out
1 10/1000Mbps Data Out
Power In/Out Port
12V/16V/24V/48V DCOut
PoE PIN
1/2（-） 3/6（+）；4/5（+) 7/8 (-)
PoE Consumption
52V 90W
LED Indicator
Power/Link
DIP Switch
12V/16V/24V/48V
Fan Quantity
Fanless
Background Bandwidth
2Gbps
Transmission Method
Store-And-Forward
Protection Level
6kV Lightning protection
6kV ESD Contact discharge
Advanced Functions
Mac Address Auto-Learning And Auto-Aging
Store and forward
IEEE 802.3x flow control for
Full-duplex Mode
Backpressure for Half-duplex Mode
OTHERS
Certification
CE, FCC, RoHS
Package Dimension
205×134×47mm
DeviceDimension
186×93×41mm
Gross Weight
0.46kg
Net Weight
0.35kg
Package Contents
1 x PoE Switch
1 x Power Cord
1 x Quick Installation Guide
Operating Temperature
-40°C~80°C
